Features：
1, the main structure of the overall die-casting aluminum, enhanced load-bearing, the use of more reliable.
2, the overall degree of protection IP68
3, to adapt to the indoor and outdoor ground installation, the depth of gray processing, point by point correction, the picture is more clear and realistic.
4, super-bearing capacity of 18 tons / square meters, the unit bearing capacity of 2 tons, scrub atomization special mask, color effect outstanding.
Parameter：
| Module resolution |
Physical point spacing(mm) | 10 |
Physical density (dots / m2) | 10000 |
Luminous spot color combination | 1R1G1B |
Module resolution | 24×24 |
Module size（mm） | 240×240 |
Module resolution | 48×48 |
Module weight（kg/m2） | 30 |
LEDPackage form | three in one |
Module size (width * high *thick)mm | 480×480×60 |
Technical Parameters |
Best sight(m) | ≥10 |
Vertical viewing angle | 100°～120o |
Average power consumption（W/m2） | 300~600 |
Maximum power consumption（W/m2） | ≤800 |
graphics card | DVI Video card |
control method | Synchronous control |
Drive device | Constant current |
Drive mode | 1/4 |
Change frame frequency（Hz） | ≥60 |
refresh rate（Hz） | ≥1000 |
White balance brightness（cd/m2） | ≥3000 |
Working temperature | -20℃～50℃ |
Operating Voltage（V） | AC 220V/110V±15% 47～64Hz |
Brightness adjustment mode | 256 level |
Computer operating system | WINXP、WIN2000、WIN98 and so on |
Video signal | DVI、VGA、S-Video、RGBHV、 COMPOSITION and so on |
Control System | Video capture card (optional) + DVI graphics card + main control card + fiber transmission (optional) / (asynchronous system) |
Mean time between failures（h） | ≥10000 |
Design life（h） | 50000 |
Horizontal perspective | 120° |
Waterproof rating (front / back) | IP65/IP54 |
Working environment humidity | 10%～95% |
Grayscale | 4096 |
